Product Features:

ELECTRICAL FEATURES

• Design Type AC Induction; Nema Design A, B, C, and D
• Power Up to 500 HP – air cooled; Up to 1500 HP – liquid cooled
• Speed 3600, 1800, 1200, 900, 720, 600, 300 rpm
• Voltage Up to 600 volts
• Phase 3-Phase
• Frequency 60 Hz
• Stator M-19, M-36, or M-45 electrical steel laminations. Other lamination grades are available upon request. Hand-wound to ensure balanced and symmetrical windings.
• Rotor M-19, M-36, or M-45 electrical steel laminations. Other lamination grades are available upon request. Die-cast aluminum, copper, or copper alloy rotor construction.

MECHANICAL FEATURES

• Frame NEMA frames 56 through 449, U & T frame configurations; Liquid cooled frames 140S through 580L; Custom frames are also available, consult factory.
• Construction Cast iron or cast aluminum frame and end bells. Consult factory for stainless steel construction and/or custom design.
• Enclosures Totally Enclosed Fan Cooled (TEFC); Totally Enclosed Auxiliary Fan Cooled (A-TEFC); Totally Enclosed Non-Ventilated (TENV); Open Drip Proof (ODP); Drip Proof Fan Cooled (DPFC); Drip Proof Auxiliary Fan Cooled (A-DPFC); Totally Enclosed Water Cooled (TELC); Totally Enclosed Oil Cooled (TELCW)
• Bearings Heavy-duty steel ball, ceramic ball, or roller bearings to suit specific applications.
• Bearing Lubrication Pre-Lubricated Sealed or Shielded; Re-Greasable Open; Oil Jet; Oil Cooled
• Balance Precision and/or NEMA Standard.
• Insulation Class B, F, H and VPI.
• Mounting Foot or Footless; Precision Bracket Mounting; Conventional C or D Flange; Metric DIN Flanges.
• Accessories Temperature sensors, brakes, vibration mounts and sensors.
