Product Features:

ELECTRICAL FEATURES

• Design Type AC Induction; Design B, C, D; 1 or 2-Speed; Variable Speed
• Power 2 – 350 HP
• Speed 3600, 1800, 1200, 900 rpm; multi-speed; Variable Speed; 1000:1 Constant Torque Open Loop; 2000:1 *Constant Torque Closed Loop; other speeds also available.
• Voltage Up to 600 volts
• Phase 3-Phase
• Frequency 60 Hz, up to 133 Hz with Inverter
• Stator M-19, M-36, or M-45 Electrical steel laminations. Other lamination grades are available upon request. Hand-wound to ensure balanced and symmetrical windings.
• Rotor M-19, M-36, or M-45 Electrical steel laminations. Other lamination grades are available upon request. Die-cast aluminum, wound rotor, copper, or copper alloy rotor construction.
• Brake Direct acting magnetic disk; heavy duty brake lining; spline hub; spring-set operation; magnetically released.

MECHANICAL FEATURES

• Frame NEMA frames 56 through 449. Custom frames also available, consult factory.
• Construction Cast iron or Cast aluminum frame and end bells. Cast iron Brake housing. Consult factory for Stainless Steel construction and/or custom design.
• Enclosures Totally Enclosed Fan Cooled (TEFC); Totally Enclosed Non-Ventilated (TENV); Open Drip Proof (ODP).
• Bearings Heavy-duty Steel ball, Ceramic ball, or Roller bearings to suit specific applications.
• Bearing Lubrication Pre-Lubricated Sealed or Shielded; Re-Greasable Open
• Balance Precision and/or NEMA Standard.
• Insulation Class B, F, H and VPI.
• Mounting Foot or Footless; Precision Bracket Mounting; Conventional C or D Flange; Metric DIN Flanges.
• Accessories Encoders, Resolvers, Temperature Sensors, Brakes, Vibration Mounts and Sensors.
