Rotator Products has been providing specialty motors and hardware to support numerous industry test stand designs and implementations. We assist our customers by designing and selecting equipment to meet their design criteria.
Motors
Brakes and Brake Controls
High Speed Gear Boxes
Highspeed Precision and High Torque Couplings
Motor Controls
Specialty Cooling Systems
A World leader in high speed motor applications, Reuland is the predominant supplier of Test Stand motors for the automotive industry. Our high power density asynchronous motor designs deliver up to 1,500 HP and 50,000 rpm. Our Test Stand motors are available in both air cooled and liquid cooled enclosures and deliver maximum power and speed performance, low noise and vibration, and extremely low inertia values in an asynchronous design. With our design, analysis, and manufacturing capabilities, and years of field experience relative to rotating machinery integration, Reuland provides the ultimate advantage on your high-performance Test Stand equipment.
OVERVIEW
Electrical Features
Available Motor Products High Speed Liquid Cooled Motors; High Speed Air Cooled Motors
Design Type AC Induction; Variable Speed
Power Up to 1500 HP
Speed Up to 50,000 rpm *Higher speeds available – consult factory
Voltage Up to 600 volts
Phase 3-Phase
Frequency Up to 2000 Hz
Configuration 2-pole or 4-pole
Stator M-19 or M-36 Electrical steel laminations. Other lamination grades are available upon request. Hand-wound to ensure balanced and symmetrical windings.
Rotor M-19 or M-36 Electrical steel laminations. Other lamination grades are available upon request. Die-cast aluminum, copper, or copper alloy rotor construction. Encapsulated rotor design for ultra-high speeds.
Frame: NEMA frame 56 through 449; IEC frame 90 through 315; Reuland liquid cooled frames 140S thru 580L; Square frames and custom frames are also available, consult factory.
Construction: Cast iron or Heavy-duty steel frame and end bells. Consult factory for Stainless Steel construction and/or custom design.
Enclosures: Totally Enclosed Fan Cooled (TEFC); Totally Enclosed Auxiliary Fan Cooled (A-TEFC); Totally Enclosed Non-Ventilated (TENV); Open Drip Proof (ODP), Open Drip Proof Fan Cooled (DPFC); Open Drip Proof Auxiliary Fan Cooled (A-DPFC); Water Cooled (TEWC); Oil Cooled (TELCW)
Bearings: High-Precision, ABEC-7, Steel ball, Ceramic ball or Roller bearings to suit specific applications.
Bearing Lubrication: Pre-Lubricated Sealed or Shielded; Re-Greasable Open, Oil Jet; Oil Cooled
Balance: Precision
Insulation: Super Class H insulation with Vacuum Impregnation (VPI)
Mounting: Footed; Precision Bracket Mounting; Conventional C or D Flange; Metric DIN Flanges
Accessories: Encoders, Resolvers, Temperature Sensors, Brakes, Vibration Mounts and Sensors
Automotive
Aerospace
Military
High Speed
Test Stands and Dynos
Spindles
Rotator has provided the correct solution for many companies throughout the years. We try to help our customers solve their issues early on so they can avoid downtime and provide the necessary guidance and/or products to fix an issue as smoothly as possible.
